Brightpoint 85W E40 230Vac Energy Saving Lamp, 6500K

* Mechanical & Electrical Classifications applied as per IEC 62444 & EN 62444 **When CMP installation accessories are used. Refer to maintaining a seal for further information. ***IP68 tested to a minimum depth of 30 meters for 12 hours, alternate depths / durations can be provided upon request.

Design Specification	BS 6121:Part 1:1989, IEC 62444, EN 62444
Mechanical Classifications*	Impact = Level 8, Retention = Class D
Enclosure Protection	IK10 to IEC 62262 (20 joules) Brass & Stainless Steel only
Electrical Classifications *	Category B (Category A when used with braid, tape or pliable wire armour cables)
ATEX Certificate	CML 18ATEX1326X CML 18ATEX4318X
Code of Protection	II 2G, II 1D, Ex db IIC Gb, Ex eb IIC Gb, Ex ta IIIC Da, II 3G Ex nR IIC Gc,  I M2, Ex db I Mb, Ex eb I Mb
Compliance Standards	EN60079-0,1,7,15,31
IECEx Certificate	IECEx CML 18.0183X
Code of Protection	Ex db IIC Gb, Ex eb IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da, Ex db I Mb, Ex eb I Mb
Compliance Standards	IEC 60079-0,1,7,15,31
cCSAus Certificate (20s16 – 90)	1310517
CSAus Code of Protection	Class II, Div 2, Groups E,F and G, Class III, Enclosure Type 4X, Class I, Zone 1, AEx e II, AEx nR II
cCSA Code of Protection	Class I, Div 2, Groups A,B,C and D, Class II, Div 2, Groups E,F and G, Class III, Enclosure Type 3, 4 and 4X, Ex d IIC, Ex e IIC, Ex nR II
Compliance Standards	CAN/CSA-C22.2 No 0, 18, 25, 30, 94, 174, CAN/CSA-E60079-0, 1, 7, ANSI/UL 514B Ed 5, ANSI/UL 50 Ed 11, ANSI/UL 2225 Ed 4, UL60079-0,1,7
UL Certificate (20s16 – 90)	E200163 , E256367
Code of Protection	Class I, Zone 1, AEx e II
Compliance Standards	UL514B
EAC Certificate (Formerly GOST R, K & B)	C-GB.AA87.B.00487
CCC Certificate	2020322313002527
CCOE / PESO (India) Certificate	P444949
INMETRO Certificate	TÜV 11.0374X
RETIE Certificate	03866
UkrSEPRO	CU 19.0371X
SANS	IA MS-XPL21804 21.0011X
Marine Approvals	LRS: 01/00172, DNV: TAE000000Y, ABS: 20-LD1948801-PDA, BV: 43180/A1
SANS	MS-XPL21804 21.0011X
Ingress Protection Rating**	IP66, IP67 & IP68
Deluge Protection Compliance	DTS01 : 91
NEMA Rating**	NEMA 4X**
Cable Gland Material	Electroless Nickel Plated Brass, Copper Free (<0.4%) Aluminium, Stainless Steel
Seal Material	CMP SOLO LSF Halogen Free Thermoset Elastomer
Cable Type	Steel / Served Wire Armour (SWA), Aluminium Wire Armour (AWA), Pliable Wire Armour (PWA), Steel Tape Armour (STA), Aluminium Strip Armour (ASA), Screened Flexible (EMC) Wire Braid (e.g. CY/SY), Wire Braid Armour (e.g. SWB)
Armour Clamping	Reversible Armour Cone & AnyWay Universal Clamping Ring
Sealing Technique	Inner Bedding Sealing Ring: Compensating Displacement Seal (CDS), Outer Sheath Sealing Ring : Load Retention Seal (LRS)
Sealing Area(s)	Cable Inner Bedding & Outer Cable Sheath
Optional Accessories	Locknuts, Earth Tags, Serrated Washers, Entry Thread Seals, Shrouds,Ingress Discs
Optional Installation Tools	Spanners, Armour Former Tool

* Mechanical & Electrical Classifications applied as per IEC 62444 & EN 62444 **When CMP installation accessories are used. Refer to maintaining a seal for further information. ***IP68 tested to a minimum depth of 30 metres for 12 hours, alternate depths / durations can be provided upon request.
